All Purpose Vehicle Model HTSBAPV
The Harlan Model HTBAPV is a versatile all-purpose vehicle engineered for ground support and maintenance operations. Powered by the latest U.S. and Euro emission-compliant engines, it delivers reliable performance while meeting modern environmental standards.
With a 4,144 sq. in. flatbed featuring an anti-slip surface and a 7,000 lb (3,175 kg) load capacity, the HTBAPV is perfectly suited for safely transporting tools, parts, and equipment across the ramp. It offers a standard drawbar pull of 5,000 lb (22.2 kN), ensuring dependable towing performance for a wide range of applications.
Optional features include a complete cab assembly with heat/defrost, mirrors, beacons, telemetry systems, tilt steering, multiple hitch configurations, and suspension-style seats—making the HTBAPV a reliable and adaptable solution for today’s demanding ground support environments.
Standard Features:
Diamond-plate flatbed with rails for safe cargo handling
Cab with metal doors, rearview mirror, and dome light for operator convenience
Keyless anti-restart ignition switch for operator safety
Driver and passenger seats with seatbelts for comfort and protection
LED lighting package including two headlights, combination tail/stop, and back-up lights for visibility
Rear-mount E-hitch (other hitch options available)
LCD dash display for clear system monitoring
Ford MSG425 | Kubota V2503 | Kubota V3600 | Kubota WG3800 | Kubota V3800 | 80 V AC, 460 Ah lithium-ion battery |
Length | 177.25" (4,502.8 mm), |
Width | 60” (1,524 mm) |
Bed Length | 74" (1,879.6 mm) |
Bed Width | 56" (1,422 mm) |
| Height | 56 3/8” (1,442 mm), |
Wheelbase | 105 15/16” (2,691 mm) |
| Ground Clearance | 6” (152 mm) |
Drive Axle | Harlan off-set, |
Steer Axle | Heavy-duty Harlan |
Suspension |
Front: Leaf-spring |
Towing Coupler | E-hitch with 1" pin |
Tires | Front: 165/R13 |
Engine | Latest model US/Euro emission: diesel, gasoline, LPG, CNG |
Transmission | Automatic industrial |
Electrical | 12V System |
Cooling | Liquid-cooled radiator with integrated transmission cooler |
Steering System | Hydrostatic |
Park Brake | Electrically actuated drum |
Service Brakes |
Hydraulic, single front and rear disc |
Subject to improvement and/or change without notice
At Harlan Global Manufacturing, we stand behind the quality and reliability of every tractor we produce. Our equipment is built for long-term performance, and each model is backed by a comprehensive warranty designed to protect your investment.
Our warranties reflect Harlan’s commitment to durability, safety, and customer satisfaction. We work closely with operators and service teams to ensure every vehicle continues to perform to the highest standards throughout its service life.
Please refer to your tractor’s owner and maintenance manual for detailed warranty terms, maintenance requirements, and service documentation instructions.
For warranty questions or assistance, our support team is here to help.
Ford MSG425 |
Kubota V2503 |
Kubota V3600 |
Kubota WG3800 |
Kubota V3800 |
80 V AC, 460 Ah lithium-ion battery |
Length | 177.25" |
Width | 60” |
Bed Length | 74" |
Bed Width | 56" |
| Height | 56 3/8” |
Wheelbase | 105 15/16” |
| Ground Clearance | 6” |
Drive Axle | Harlan off-set, |
Steer Axle | Heavy-duty Harlan |
Suspension |
Front: Leaf-spring |
Towing Coupler | E-hitch |
Tires | Front: |
Engine | Latest model US/Euro emission: |
Transmission | Automatic industrial |
Electrical | 12V System |
Cooling | Liquid-cooled radiator with integrated transmission cooler |
Steering System | Hydrostatic |
Park Brake | Electrically actuated drum |
Service Brakes |
Hydraulic, |
Subject to improvement and/or change without notice
